A2 — Dornier
An air-jet loom for all kinds of labels. Historically, this is the ultimate air-jet loom.
The ideal loom to ensure efficient production processes and minimize spare part use, thanks to its automation and advanced technology. technology. It allows for label cutting and ironing in a single pass, increasing high-volume production and allowing for complete personalization based on the brand’s specifications. It is also able to handle a wide range of sizes and up to 8 color yarns, ensuring flexibility and versatility in the production process.
Features
Loom manufacturer Dornier
Speed up to 1050 rpm based on the jacquard loom configuration
Nominal height 1800mm
Reed height 1600mm
Configuration
- Taffeta (8x200mm - 4x400mm)
- Satin (8x200mm)
- Custom Configurations
Number of colors 8
Power consumption 12Kw/h (in operation) 22Kw/h (at startup)
Air consumption 80 to 90 m3/h at 3/3,5 bar
Arrival air pressure 7 bar
Dimensions L 5100 mm x H 4100 mm x D 1800 mm
Compatible accessories
MEI Thermal Cutting System
MEI Ironing System
MEI Labels Tension Control
